2013 Tmax 530
Yamaha XP 530 T-Max
| Make Model | Yamaha XP 530 T-Max |
| Year | 2012 - 13 |
| Engine | Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder. |
| Capacity | 530 cc / 32.34 cu-in |
| Bore x Stroke | 68.0 x 73.0 mm |
| Cooling System | Liquid cooled |
| Compression Ratio | 10:9 : 1 |
| Lubrication | Semi-dry-sump |
| Induction | Injection. Electronic fuel injection |
| Ignition | TCI |
| Starting | Electric |
| Max Power | 45.8 hp / 34.2 kW @ 6750 rpm |
| Max Torque | 52.3 Nm / 38.6 ft.lbs @ 5250 rpm |
| Clutch | Wet, multiple-disc automatic |
| Transmission | Fully automatic CVT |
| Final Drive | V-Belt |
| Front Suspension | 43mm Telescopic forks |
| Front Wheel Travel | 120 mm / 4.7 in |
| Rear Suspension | Swingarm - single shock |
| Rear Wheel Travel | 116 mm / 4.6 in |
| Front Brakes | 2x 267 discs |
| Rear Brakes | Single 267 disc |
| ABS | Standard |
| Front Tyre | 120/70-15 |
| Rear Tyre | 160/60-15 |
| Dimensions | Length 2200mm / 86.6 in Width 775mm / 30.5 in Height 1420 or 1475mm / 55.9 or 58.1 in |
| Ground Clearance | 125mm / 4.9 in |
| Wheelbase | 1580mm / 62.2 in |
| Maximum Load | 197kg / 434 lbs |
| Seat Height | 800 mm / 31.5 in |
| Dry Weight | 203 kg / 447.5 lbs - ABS 208 kg / 458.5 lbs |
| Wet Weight | 218 kg / 481 lbs |
| Fuel Capacity | 15 Litters / 4 gal |
Yamaha�s T-Max. Lighter and more powerful, the 2012 T-Max includes numerous changes and refinements. First and foremost, engine displacement has increased from 499 cc to 530 cc, and �rebuilt with a host of lighter, more efficient components.� Yamaha claims this results in a huge boost in low to mid-speed power and torque. A new belt drive system provides a claimed increase in efficient power transfer together with a more connected feel between the throttle and the rear wheel.
Redesigned seating includes more comfortable passenger accommodations and hand grips. A new automotive-style dashboard provides extremely thorough instrumentation with excellent legibility. A larger 282 mm rear disc brake combines with the already powerful dual front brake system. The all-new bodywork includes a two-step adjustable windscreen. The Yamaha T-Max has previously set the bar for maxi-scooters when it comes to handling, and Yamaha claims improvements in this category, as well.
